1 About this Manual
This Manual contains information about the parameterisation & configuration of the
9400 HighLine controller by means of the L-force »Engineer« and the keypad.
The information in this Manual applies to the following "9400 Servo Drives":
1.1 Conventions used
This Manual uses the following conventions to distinguish between different types of
information:
Note!
The Manual supplements the Mounting Instructions attached to the controller
and the Manual for the 9400 HighLine controller.
The Mounting Instructions contain safety information which must be observed!
Type Type designation As of hardware
version
As of software
version
9400 HighLine
(Single Drive & Multi Drive)
E94AxHExxxx PD 1.37.00
Type of information Writing Examples/notes
Variable identifier Italics By setting bEnable to TRUE...
Window range The Message window... / The Options dialog box...
Control element Bold The OK button... / The Copy command... / The Properties index card... /
The Name input field...
Sequence of
menu commands
If the execution of a function requires several commands, the individual
commands are separated by an arrow: Select File Open to...
Shortcut Use to open the online help.
If a command requires a combination of keys, a "+" is placed between
the key symbols:
Use + to...
Program code
Courier
IF var1 < var2 THEN
a = a + 1
END IF
Keyword
Courier
bold
Hyperlink Underlined A hyperlink is an optically highlighted reference which is activated with
a mouse click.
Step-by-step
instruction
M Like safety information, step-by-step instructions are indicated by a
pictograph.
