9400 HighLine | Parameter setting & configuration
Diagnostics & error analysis
Error messages of the operating system
500 Firmware 1.37 - 09/2006
L
Position value faulty [0x00910010]
Error during initialisation [0x00910011]
Blocking function in MEC task [0x00910012]
Safety module: Incompatible to setting under C00214 [0x00920000]
DFIN (MXI1): A-/A track error [0x00990000]
DFIN (MXI1): B-/B track error [0x00990001]
Response (Lenze setting printed in bold)
None System fault : Fault Trouble Quick stop by trouble Warning locked Warning Information
Cause Remedy
Internal error If the error occurs frequently, please contact Lenze.
Response (Lenze setting printed in bold)
None : System fault Fault Trouble Quick stop by trouble Warning locked Warning Information
Cause Remedy
Internal error If the error occurs frequently, please contact Lenze.
Response (Lenze setting printed in bold)
None System fault : Fault Trouble Quick stop by trouble Warning locked Warning Information
Cause Remedy
Internal error If the error occurs frequently, please contact Lenze.
Response (Lenze setting printed in bold)
None : System fault Fault Trouble Quick stop by trouble Warning locked Warning Information
Cause Remedy
The controller has detected a safety module which does
not match the setting under C00214 .
Change setting under C00214 or use a suitable safety
module.
• Then, restart the controller.
Response (Lenze setting printed in bold) Setting: C13040 (; Adjustable response)
; None System fault : Fault ; Trouble ; Quick stop by trouble ; Warning locked ; Warning ; Information
Cause Remedy
Digital frequency extension module in MXI1:
Interruption (open circuit) of the signal cable for track A.
• Check signal cable for track A.
• Check encoder.
Response (Lenze setting printed in bold) Setting: C13040 (; Adjustable response)
; None System fault : Fault ; Trouble ; Quick stop by trouble ; Warning locked ; Warning ; Information
Cause Remedy
Digital frequency extension module in MXI1:
Interruption (open circuit) of the signal cable for track B.
• Check signal cable for track B.
• Check encoder.
