C02521, C02522, C02523 – Lenze E94AxHE Servo Drives 9400 HighLine (Firmware 01-37) User Manual
Page 615: C02524, C02525, C02526, Unit in, Is made in the unit defined in, And the feed constant, 9400 highline | parameter setting & configuration
L
Firmware 1.37 - 09/2006
615
9400 HighLine | Parameter setting & configuration
Parameter reference
Parameter list | C02521
C02521
C02522
C02523
C02524
C02525
C02526
Parameter | Name:
C02521 | Gearbox fact. denom. motor
Data type: INTEGER_32
Index: 22054
d
= 5626
h
Setting range
(min. value | unit | max. value)
Lenze setting
1
2147483647 1
;
Read access ; Write access ; CINH PLC STOP No transfer COM MOT
Parameter | Name:
C02522 | Gearbox fact. numer. load
Data type: INTEGER_32
Index: 22053
d
= 5625
h
Setting range
(min. value | unit | max. value)
Lenze setting
1
2147483647 1
;
Read access ; Write access ; CINH PLC STOP No transfer COM MOT
Parameter | Name:
C02523 | Gearbox fact. denom. load
Data type: INTEGER_32
Index: 22052
d
= 5624
h
Setting range
(min. value | unit | max. value)
Lenze setting
1
2147483647 1
;
Read access ; Write access ; CINH PLC STOP No transfer COM MOT
Parameter | Name:
C02524 | Feed constant
Data type: UNSIGNED_32
Index: 22051
d
= 5623
h
Setting range
(min. value | unit | max. value)
Lenze setting
0.0001
Unit/rev.
214748.3647 360.0000 Unit/rev.
;
Read access ; Write access ; CINH PLC STOP No transfer COM MOT Scaling factor: 10000
Parameter | Name:
C02525 | Unit
Data type: UNSIGNED_32
Index: 22050
d
= 5622
h
Selection list
(Lenze setting printed in bold)
Information
0 User-defined
The text entered in
is displayed for the unit.
1 Incr.
2 μm
3 mm
4 M
5 inch
6 yard
7 °
;
Read access ; Write access ; CINH PLC STOP No transfer COM MOT
Parameter | Name:
C02526 | User-defined unit
Data type: VISIBLE_STRING
Index: 22049
d
= 5621
h
User-defined unit which is displayed when
="0" is selected.
;
Read access ; Write access ; CINH PLC STOP No transfer COM MOT
