L
Firmware 1.37 - 09/2006
247
9400 HighLine | Parameter setting & configuration
Standard TAs
TA "Actuator – speed" | Assignment of the I/O terminals
11.2.2.2
Actual value and status signals
The following tables contain the Lenze assignment of the analog and digital outputs for
the technology application "actuator – speed".
r
The default signal configuration if required can be easily changed by parameterising
the multiplexer parameters assigned.
Analog outputs
Digital outputs
State bus
Terminal X3
Signal (Lenze setting)
Signal configuration
AO1
Motor speed
• Scaling: ±10 V ≡ motor reference speed (
)
C03110/1
AO2
Motor torque (setpoint)
• Scaling: ±10 V ≡ Motor reference torque (
C03110/2
I/O terminals Analog outputs (C 120)
Terminal X4
Signal (Lenze setting)
Signal configuration
DO1
Status "Drive ready"
• This operating state is active if the controller is enabled by setting
the digital input RFR to HIGH level and no error has occurred.
C03100/1
DO2
Status "Speed follower enabled"
• The speed follower has been enabled via the digital input DI2.
C03100/2
DO3
Status "Speed follower in limitation"
• The enabled speed follower is in the limitation for more than
100 ms.
• The setpoint is limited to the upper or lower speed limit value
) .
C03100/3
DO4
Status "Error active acknowledgement is required"
• Monitoring with the error response "Error" or "Quick stop by
trouble" has been activated, and the controller is in the device
state "Error active" or "Quick stop by trouble active".
C03100/4
I/O terminals Digital outputs (C 125)
Terminal X2
Signal (Lenze setting)
Signal configuration
SB
Status "Speed follower in limitation"
• The enabled speed follower is in the limitation for more than
100 ms.
• The setpoint is limited to the upper or lower speed limit value
) .
• The state bus is put in the "error" status.
C03100/5
I/O terminals Monitoring function "State bus" (C 127)
GA
AO1
AO2
GO
24O
DO1
DO2
DO3
DO4
GE
24E
SB
