9400 HighLine | Parameter setting & configuration
Parameter reference
Parameter list | C00078
552
Firmware 1.37 - 09/2006
L
C00078
C00079
C00080
C00081
C00082
C00083
C00084
C00085
Parameter | Name:
C00078 | Field contr. reset time
Data type: UNSIGNED_32
Index: 24497
d
= 5FB1
h
Setting range
(min. value | unit | max. value)
Lenze setting
1.0
ms
6000.0 15.1 ms
;
Read access ; Write access CINH PLC STOP No transfer COM ; MOT Scaling factor: 10
Parameter | Name:
C00079 | Motor - mutual inductance
Data type: UNSIGNED_32
Index: 24496
d
= 5FB0
h
Display range
(min. value | unit | max. value)
0.0
mH
214748364.7
;
Read access Write access CINH PLC STOP No transfer COM MOT Scaling factor: 10
Parameter | Name:
C00080 | Resolver - number of pole pairs
Data type: UNSIGNED_32
Index: 24495
d
= 5FAF
h
Setting range
(min. value | unit | max. value)
Lenze setting
1
10 1
;
Read access ; Write access ; CINH PLC STOP No transfer COM ; MOT
Parameter | Name:
C00081 | Rated motor power
Data type: UNSIGNED_32
Index: 24494
d
= 5FAE
h
Setting range
(min. value | unit | max. value)
Lenze setting
0.01
kW
500.00 0.25 kW
;
Read access ; Write access ; CINH PLC STOP No transfer COM ; MOT Scaling factor: 100
Parameter | Name:
C00082 | Motor rotor resistance
Data type: UNSIGNED_32
Index: 24493
d
= 5FAD
h
Display range
(min. value | unit | max. value)
0.0000
Ohm
214748.3647
;
Read access Write access CINH PLC STOP No transfer COM MOT Scaling factor: 10000
Parameter | Name:
C00083 | Motor - rotor time constant
Data type: UNSIGNED_32
Index: 24492
d
= 5FAC
h
Display range
(min. value | unit | max. value)
0.00
ms
21474836.47
;
Read access Write access CINH PLC STOP No transfer COM MOT Scaling factor: 100
Parameter | Name:
C00084 | Motor stator resistance
Data type: UNSIGNED_32
Index: 24491
d
= 5FAB
h
Setting range
(min. value | unit | max. value)
Lenze setting
0.0000
Ohm
125.0000 18.2200 Ohm
;
Read access ; Write access ; CINH PLC STOP No transfer COM ; MOT Scaling factor: 10000
Parameter | Name:
C00085 | Motor stator leakage induct.
Data type: UNSIGNED_32
Index: 24490
d
= 5FAA
h
Setting range
(min. value | unit | max. value)
Lenze setting
0.000
mH
500.000 51.000 mH
;
Read access ; Write access ; CINH PLC STOP No transfer COM ; MOT Scaling factor: 1000
