9400 HighLine | Parameter setting & configuration
Parameter reference
Parameter list | C01196
610
Firmware 1.37 - 09/2006
L
C01196
C01203
C01204
C01205
C01206
C01208
Parameter | Name:
C01196 | S1 torque characteristic I²xt mon.
Data type: UNSIGNED_32
Index: 23379
d
= 5B53
h
I
2
xt motor monitoring: Speed-dependent evaluation of the motor current
• By selecting a characteristic the permissible motor current is evaluated depending on speed for calculating the
thermal motor utilisation.
Setting range
(min. value | unit | max. value)
0
%
600
Subcodes
Lenze setting
Information
C01196/1
0 %
S1 torque characteristic n1/nn
C01196/2
100 %
S1 torque characteristic I1/In
C01196/3
0 %
S1 torque characteristic n2/nn
C01196/4
100 %
S1 torque characteristic I2/In
C01196/5
100 %
S1 torque characteristic n3/nn
C01196/6
100 %
S1 torque characteristic I3/In
C01196/7
100 %
S1 torque characteristic n4/nn
C01196/8
100 %
S1 torque characteristic I4/In
;
Read access ; Write access CINH PLC STOP No transfer COM ; MOT
Parameter | Name:
C01203 | Counter: Brake chopper overload
Data type: UNSIGNED_16
Index: 23372
d
= 5B4C
h
Display range
(min. value | unit | max. value)
0
65535
;
Read access Write access CINH PLC STOP No transfer COM MOT
Parameter | Name:
C01204 | Counter: Ixt overload
Data type: UNSIGNED_16
Index: 23371
d
= 5B4B
h
Display range
(min. value | unit | max. value)
0
65535
;
Read access Write access CINH PLC STOP No transfer COM MOT
Parameter | Name:
C01205 | Counter: DC bus overvoltage
Data type: UNSIGNED_16
Index: 23370
d
= 5B4A
h
Display range
(min. value | unit | max. value)
0
65535
;
Read access Write access CINH PLC STOP No transfer COM MOT
Parameter | Name:
C01206 | Counter: Mains switching
Data type: UNSIGNED_16
Index: 23369
d
= 5B49
h
Display range
(min. value | unit | max. value)
0
65535
;
Read access Write access CINH PLC STOP No transfer COM MOT
Parameter | Name:
C01208 | Counter: heatsink overtemp.
Data type: UNSIGNED_16
Index: 23367
d
= 5B47
h
Display range
(min. value | unit | max. value)
0
65535
;
Read access Write access CINH PLC STOP No transfer COM MOT
