9400 HighLine | Parameter setting & configuration
Parameter reference
Parameter list | C02549
620 Firmware 1.37 - 09/2006
L
C02549
C02550
C02552
Parameter | Name:
C02549 | Drive interface: Signals
Data type: UNSIGNED_32
Index: 22026
d
= 560A
h
Display of the boolean signals of the drive interface (LS_DriveInterface).
Selection list
0 FALSE
1 TRUE
Subcodes Information
C02549/1 DI_bSetCInh
C02549/2 Reserved
C02549/3 Reserved
C02549/4 DI_bSwitchOn
C02549/5 Reserved
C02549/6 DI_bReady
C02549/7 DI_bFailActive
C02549/8 DI_bImpActive
C02549/9 DI_bCInhActive
C02549/10 DI_bWarningActive
C02549/11 DI_bUVDetected
C02549/12 DI_bOVDetected
C02549/13 DI_bMainSupplyOk
C02549/14 DI_bReadyToSwitchOn
C02549/15 DI_bOperationEnabled
; Read access Write access CINH PLC STOP No transfer COM MOT
Parameter | Name:
C02550 | Setpoint interpolation
Data type: UNSIGNED_32
Index: 22025
d
= 5609
h
Motor interface
Selection list
0 Off
1 ON
Subcodes Lenze setting Information
C02550/1 0: Off Position setpoint interpolat.
C02550/2 0: Off Speed setpoint interpolat.
C02550/3 0: Off Torque setpoint interpolat.
; Read access ; Write access CINH PLC STOP No transfer COM MOT
Parameter | Name:
C02552 | Position setpoint
Data type: INTEGER_32
Index: 22023
d
= 5607
h
Motor interface
Display range (min. value | unit | max. value)
-214748.3647 Unit 214748.3647
; Read access Write access CINH PLC STOP No transfer COM MOT Scaling factor: 10000
