Chapter 1 Specifications Check
1.2.4 Selection of the Circuit Breaker 1.2.5 Selection of the Leakage Breaker
53
1.2.4 Selection of the Circuit Breaker
For the selection of the circuit breaker, perform it according to the following items.
� 3 times of the rated current flows to the controller during the acceleration/deceleration.
Select one that does not trip when the above current passes. When it trips, select the
breaker with a rated current one rank above. (Refer to the Operation Characteristic Curve
described in the catalogue of each manufacturer.)
� Select the breaker that does not trip with the rush current. (Refer to the Operation
Characteristic Curve described in the catalogue of each manufacturer.)
� For the rated breaking current, select the current value which can break the current even
when a short circuit occurs.
Rated Breaking Current > Short-circuit Current = Primary Power Supply Capacity/Power
Voltage
� Consider margin for the rated current on the circuit breaker.
Rated Current of Circuit Breaker >
Rated Voltage Amperage [VA] / AC Input Voltage × Margin (1.2 to 1.4 for reference)�
1.2.5 Selection of the Leakage Breaker
� Regarding the leakage breaker, it is necessary to have a clear purpose for selection such
as a fire protection or protection of human body.
� Leak current varies depending on the capacity of connected motor, cable length and the
surrounding environment. Measure the leak current at the point where a ground fault
circuit interrupter is to be installed when leakage protection is conducted.
� Use the harmonic type for a leakage breaker.
