Chapter 6 Parameter
6.3.2 For XSEL-RX/SX, RXD/SXD
359
Axis-Specific Parameters (XSEL-RX/SX, RXD/SXD)
No. Parameter name
Default value
(reference)
Input range Unit Remarks No.
46 (For expansion) 0 0
47 Screw Lead 20000 20000
1 to
99999999
0.001mm Valid only when linear sliding axis
Invalid when linear encoder
48 (For expansion) 0 0
49 (For expansion) 0 0
50 Gear Ratio Numerator 1, 1, 11, 1 1
1 to
99999999
Invalid when linear encoder
51 Gear Ratio Denominator 50, 50, 10, 15 1
1 to
99999999
Invalid when linear encoder
