Chapter 7
Troubleshooting
7.3 Error List (MAIN application)
467
� Error List (MAIN core)
In the panel window, the error numbers follow E in the display.
Error
No.
Error name Description, action, etc.
A70 SCIF overrun error Communication error.
Check for noise, connected equipment and communication
setting. (When updating the application, connect to a PC
and use IAI’s update tool.)
A71 SCIF framing error Communication error.
Check for noise, shorted/disconnected communication
cable, connected equipment and communication setting.
(When updating the application, connect to a PC and use
IAI’s update tool.)
A72 SCIF parity error Communication error.
Check for noise, shorted/disconnected communication
cable, connected equipment and communication setting.
(When updating the application, connect to a PC and use
IAI’s update tool.)
A73 IAI protocol header error Communication protocol error.
Check for noise and connected equipment. (When
updating the application, connect to a PC and use IAI’s
update tool.)
A74 IAI protocol terminal ID error Communication protocol error.
Check for noise and connected equipment. (When
updating the application, connect to a PC and use IAI’s
update tool.)
A75 IAI protocol command ID error Communication protocol error.
Check for noise and connected equipment. (When
updating the application, connect to a PC and use IAI’s
update tool.)
A76 IAI protocol checksum error Communication protocol error.
Check for noise and connected equipment. (When
updating the application, connect to a PC and use IAI’s
update tool.)
A77 Motorola S record type error The update program file is invalid. Check the file.
A78 Motorola S checksum error The update program file is invalid. Check the file.
A79 Motorola S load address error The update program file is invalid. Check the file.
A7A Motorola S write address over error The update program file is invalid. Check the file.
A7B Flash timing limit over error (Write) Error writing the flash ROM (When updating)
A7C Flash timing limit over error (Erase) Error erasing the flash ROM (When updating)
A7D Flash verify error
Error erasing/writing the flash ROM (When updating)
A7E Flash ACK timeout Error erasing/writing the flash ROM (When updating)
A7F Head sector number specification
error
Error erasing the flash ROM (When updating)
A80 Sector count specification error Error erasing the flash ROM (When updating)
A81 Write-destination offset address
error (Odd-numbered address)
The address written during flash ROM write (when
updating) is invalid. Check the update program file.
A82 Write-source data buffer address
error (Odd-numbered address)
Error writing the flash ROM (When updating)
A83 Invalid code sector block ID error The flash ROM is new, or the program currently written to
the flash ROM is invalid because the last update was
aborted. The ROM can be updated without problem.
M
es
sa
ge
le
ve
l e
rro
rs
A84 Code sector block ID erase count
over
The number of times the flash ROM was erased exceeded
the allowable count.
