Chapter 6 Parameter
6.1 I/O Parameter (All types)
282
I/O Parameter (All types)
No. Parameter name
Default
value
(reference)
Input
range
Unit Remarks
30 Input function selection 000 1 0 to 5
0: General-purpose input
1: Program start signal (ON edge)
(Input ports 007 to 013, BCD-specified
program number)
2: Program start signal (ON edge)
(Input ports 007 to 013, binary-specified
program number)
3: Program start signal (ON edge)
(Input ports. 008 to 014, BCD-specified
program number)
Note: The function of “I/O parameter No. 44,
Input function selection 014” (relating to
drive-source cutoff reset) is assigned to
“I/O parameter No. 37, Input function
selection 007,” while the function of “I/O
parameter No. 43, Input function selection
013” (error reset, program number
specified for program start) is assigned to
“I/O parameter No. 44, Input function
selection 014.”
To specify a program number of 7 bit long,
“1: Program number specified for program
start” must be set for “I/O parameter No.
38, Input function selection 008” through
“I/O parameter No. 44, “Input function
selection 014.”
4: Program start signal (ON edge)
(Input ports. 008 to 014, binary-specified
program number)
Note: The function of “I/O parameter No. 44,
Input function selection 014” (relating to
drive-source cutoff reset) is assigned to
“I/O parameter No. 37, Input function
selection 007,” while the function of “I/O
parameter No. 43, Input function selection
013” (error reset, program number
specified for program start) is assigned to
“I/O parameter No. 44, Input function
selection 014.”
To specify a program number of 7 bit long,
“1: Program number specified for program
start” must be set for “I/O parameter No.
38, Input function selection 008” through
“I/O parameter No. 44, “Input function
selection 014.”
* When using this signal to start a program, make
sure the signal remains ON for 100 msec or
longer so that the program will start without fail.
* Program Nos. 1 to 79 can be started via BCD
specification, while program Nos. 1 to 127 can
be started via binary specification. Program No.
128 cannot be started with this signal.
Note: The port number assigned to this function
can be changed using I/O parameter No.
283, “Port number assigned to input
function selection 000.”
31 Input function selection 001 0 0 to 5
0: General-purpose input
1: Software reset signal (1 sec ON)
* If continued operation is specified as the action
upon emergency stop, enable the software
reset signal (to provide a means of canceling
the operation).
Note: The port number assigned to this function
can be changed using I/O parameter No.
284, “Port number assigned to input
function selection 001.”
