Chapter 6 Parameter
6.1 I/O Parameter (All types)
280
I/O Parameter (All types)
No. Parameter name
Default
value
(reference)
Input
range
Unit Remarks
17
Network I/F Module 1
Fix-Allocated Output Port Start
No.
-1 -1 to 6999
300+(Multiples of 8)(300 to 599)
4000+(Multiples of 8)(4000 to 6999)(Invalid if a
negative value is set.)
18 Network I/F module error
monitor
1 0 to 5
0: Do not monitor
1: Monitor
* Some exceptions apply.
19 (For expansion) 0
20 Input Filtering Periods 2 1 to 9 msec Input signal is recognized when the status is held
for twice the period set by this parameter.
21 Reserved by the system
(change is prohibited)
0 1 to 9
22 Reserved by the system
(change is prohibited)
2000 0 to 99999 msec
23
Overcurrent/power-supply error
detection input specification for
multi-point DIO external
terminal block
0H
0H to
FFFFFFFFH
Bits 0 to 3: I/O Slot 1 (I/O1) Reserved by the
system
Bits 4 to 7: I/O Slot 2 (I/O1) Reserved by the
system
Bits 8 to 11: System Reservation
Bits 12 to 15: System Reservation
(0: Do not use error detection input
1: Use error detection input = IN023 on card
2: Use error detection input = IN047 on card
3: Use error detection input = IN023/47 on
card)
* Determine an appropriate setting after checking
the specification of the multi-point DIO terminal
block unit to be connected.
* The input port used for the error detection input
cannot be used as a general-purpose input port.
