Chapter 6 Parameter
6.1 I/O Parameter (All types)
324
I/O Parameter (All types)
No.
Parameter name
Default
value
(reference)
Input
range
Unit
Remarks
715 Extension I/O Unit error
monitor
1
0 to 5
0: No Monitoring,
1: Monitoring
2: Monitoring (Not to monitor 24V I/O power
related error)
3: Monitoring (To monitor only 24V I/O power
related error)
4: Monitoring (makes 24V I/O Power Supply
Related Error message level)
* There are some exceptions
* If set to 0 (= No Monitoring) or 2 (= Monitoring
(Not to monitor 24V I/O power related error)),
system error would not occur when in 24V I/O
power related error, however, the actual output
of the digital I/O board will be shut off on the
circuit later for the purpose of the extension I/O
unit protection.
716
Extension I/O Unit
Multi-Channel DIO External
Terminal Block Overcurrent /
Power Supply Failure Detection
Input Indication
0H
0H to
FFFFFFFFH
Bits 0 to 3: Extension I/O unit slot 1 input
indication
Bits 4 to 7: Extension I/O unit slot 2 input
indication
Bits 8 to 11: Extension I/O unit slot 3 input
indication
Bits 12 to 15: Extension I/O unit slot 4 input
indication
(0: Error detection not to be input
1: Error detection input = IN023 in
card
2: Error detection input = IN047 in
card
3: Error detection input = IN023/47 in
card)
* See the specification of the connected terminal
unit for the multi-channel DIO for setting.
* The input port used as the error detection input
cannot be used as a general-purposed input
port.
717 (For expansion)
0
718 (For expansion)
0
719 (For expansion)
0
720 (For expansion)
0
721 (For expansion)
0
722 (For expansion)
0
723 (For expansion)
0
724 (For expansion)
0
725 (For expansion)
0
726 (For expansion)
0
727 (For expansion)
0
728 (For expansion)
0
729 (For expansion)
0
730 (For expansion)
0
731 (For expansion)
0
732 (For expansion)
0
733 (For expansion)
0
734 (For expansion)
0
735 (For expansion)
0
736 (For expansion)
0
737 (For expansion)
0
738 (For expansion)
0
739 (For expansion)
0
740 (For expansion)
0
741 (For expansion)
0
742 (For expansion)
0
743 (For expansion)
0
