Chapter 1 Specifications Check
1.2.2 XSEL-RX/SX Controller
Type
47
[Calculation Example]
Shown below is an example for how to calculate the power capacity and amount of heat
generation when the following actuators are used.
SCARA Robot: IX-NNN5020H
Short-Axis Actuator: Axis 5 Actuator 200W
� � � � � � � � � Axis 6 Actuator 100W w/ brake�
Standard Type Controller �Option: PIO Board 1 sheet, Device Net�
Teaching Pendant (IAI Standard Type)�
� �
1) Control Power Capacity�
Base Unit Quantity Power consumption
(Per Unit)
Total [VA]
Base Unit
�
31.4 31.4
Driver 3 6.26 18.78
Encoder 6 2.38 + 3.57 35.7
Fan Unit 6 5.71 34.26
PIO Board 1 5.95 5.95
Device Net
�
1.98 1.98
Teaching pendant 1 3.57 3.57
Brake 1 0.42 0.42
Totalizer 132.06
2) Heat Generation of Control System�
Base Unit Quantity Power consumption
(Per Unit)
Total [VA]
Base Unit � 31.4 31.4
Driver 3 6.26 18.78
Encoder 6 2.38 14.28
Fan Unit 6 5.71 34.26
PIO Board 1 5.95 + 14.52 20.47
Device Net
�
1.98 + 3.43 5.41
Brake 1 7.92 7.92
Totalizer 132.52
Heat Generation [W] = Totalizer [VA] × 0.7(Efficiency)×0.6(Power Factor)
55.66
�
3) I/O (PIO board) Power Capacity (24V DC)�
14.52 × 1 = 14.52 [VA]
4) Brake Power Capacity (24V DC)
(2.5 + 1) Ч 1 +(2.5 + 5.8) Ч1 = 11.8 [VA]
5) Motor Power Capacity
SCARA Axes: 3696.7[VA]
Single-Direction Axis: 421 + 234 = 655 [VA]
3696.7 + 655 = 4351.7 [VA]
6) Motor Power Supply Heat Generation
69.7 + 9.12 + 6.12 = 81.91 [W]
7) Rated Power Capacity =
1) Control Power Capacity + 5) Motor Power Capacity = 132.06+ 4351.7 = 4483.76 [VA]
8) Heat Generation =
2) Heat Generation of Control System + 6) Motor Power Supply Heat Generation = 55.66
+ 81.94 = 137.6 [W]
