IAI America XSEL-S - Manual (Page 325)

Chapter 6 Parameter
6.1 I/O Parameter (All types)
317
I/O Parameter (All types)
No. Parameter name
Default
value
(reference)
Input
range
Unit Remarks
538
Extension Motion Control
Board 1 st Axis Control Top Input
Port Number
0 0 to 3999 Note: Dedicated for XSEL-R/S controller
539
Extension Motion Control
Board 1 st Axis Control Top
Output Port Number
0 0 to 6999 Note: Dedicated for XSEL-R/S controller
540 Extension Motion Control
Board 2 nd Axis Control Attribute 00000000H
0H to
FFFFFFFFH
(*Same as I/O parameter No. 534)
Note: Dedicated for XSEL-R/S controller
541
Extension Motion Control
Board 2 nd Axis Control Top
Input Port Number
0 0 to 3999 Note: Dedicated for XSEL-R/S controller
542
Extension Motion Control
Board 2 nd Axis Control Top
Output Port Number
0 0 to 6999 Note: Dedicated for XSEL-R/S controller
543 Extension Motion Control
Board 3 rd Axis Control Attribute 00000000H
0H to
FFFFFFFFH
(*Same as I/O parameter No. 534)
Note: Dedicated for XSEL-R/S controller
544
Extension Motion Control
Board 3 rd Axis Control Top Input
Port Number
0 0 to 3999 Note: Dedicated for XSEL-R/S controller
545
Extension Motion Control
Board 3 rd Axis Control Top
Output Port Number
0 0 to 6999 Note: Dedicated for XSEL-R/S controller
546 Extension Motion Control
Board 4 th Axis Control Attribute 00000000H
0H to
FFFFFFFFH
(*Same as I/O parameter No. 534)
Note: Dedicated for XSEL-R/S controller
547
Extension Motion Control
Board 4 th Axis Control Top Input
Port Number
0 0 to 3999 Note: Dedicated for XSEL-R/S controller
548
Extension Motion Control
Board 4 th Axis Control Top
Output Port Number
0 0 to 6999 Note: Dedicated for XSEL-R/S controller
549 Extension Motion Control
Board 5 th Axis Control Attribute 00000000H
0H to
FFFFFFFFH
(*Same as I/O parameter No. 534)
Note: Dedicated for XSEL-R/S controller
550
Extension Motion Control
Board 5 th Axis Control Top Input
Port Number
0 0 to 3999 Note: Dedicated for XSEL-R/S controller
551
Extension Motion Control
Board 5 th Axis Control Top
Output Port Number
0 0 to 6999 Note: Dedicated for XSEL-R/S controller
552 Extension Motion Control
Board 6 th Axis Control Attribute 00000000H
0H to
FFFFFFFFH
(*Same as I/O parameter No. 534)
Note: Dedicated for XSEL-R/S controller
553
Extension Motion Control
Board 6 th Axis Control Top Input
Port Number
0 0 to 3999 Note: Dedicated for XSEL-R/S controller
554
Extension Motion Control
Board 6 th Axis Control Top
Output Port Number
0 0 to 6999 Note: Dedicated for XSEL-R/S controller
555 Extension Motion Control
Board 7 th Axis Control Attribute 00000000H
0H to
FFFFFFFFH
(*Same as I/O parameter No. 534)
Note: Dedicated for XSEL-R/S controller
556
Extension Motion Control
Board 7 th Axis Control Top Input
Port Number
0 0 to 3999 Note: Dedicated for XSEL-R/S controller
557
Extension Motion Control
Board 7 th Axis Control Top
Output Port Number
0 0 to 6999 Note: Dedicated for XSEL-R/S controller
558 Extension Motion Control
Board 8 th Axis Control Attribute 00000000H
0H to
FFFFFFFFH
(*Same as I/O parameter No. 534)
Note: Dedicated for XSEL-R/S controller
559
Extension Motion Control
Board 8 th Axis Control Top Input
Port Number
0 0 to 3999 Note: Dedicated for XSEL-R/S controller
560
Extension Motion Control
Board 8 th Axis Control Top
Output Port Number
0 0 to 6999 Note: Dedicated for XSEL-R/S controller
