Chapter 6 Parameter
6.1 I/O Parameter (All types)
323
I/O Parameter (All types)
No. Parameter name
Default
value
(reference)
Input
range
Unit Remarks
696
Communication Shared
Memory Reference Work
Pattern among IA Net
Controllers (127-96)
0H
0H to
FFFFFFFFH
(Same as I/O parameter No. 693)
697
Communication Shared
Memory Reference Work
Pattern among IA Net
Controllers (159-128)
0H
0H to
FFFFFFFFH
(Same as I/O parameter No. 693)
698
Communication Shared
Memory Reference Work
Pattern among IA Net
Controllers (191-160)
0H
0H to
FFFFFFFFH
(Same as I/O parameter No. 693)
699
Communication Shared
Memory Reference Work
Pattern among IA Net
Controllers (223-192)
0H
0H to
FFFFFFFFH
(Same as I/O parameter No. 693)
700
Communication Shared
Memory Reference Work
Pattern among IA Net
Controllers (255-224)
0H
0H to
FFFFFFFFH
(Same as I/O parameter No. 693)
701
Number of Communication
Output Ports Used among IA
Net Controllers
0 0 to 256 Multiples of 16
702 (For expansion) 0
703 (For expansion) 0
704 (For expansion) 0
705 Extension I/O Unit Use Select 0H
0H to
FFFFFFFFH
Bits 0 to 3: Select to use Slot 1
Bits 4 to 7: Select to use Slot 2
Bits 8 to 11: Select to use Slot 3
Bits 12 to 15: Select to use Slot 4
(0: Not to use,
1: Use DO,
2: Use DI,
3: Use DO+DI)
706 Extension I/O Unit Number 1H 0H to FH
Set the unit number of the used extension I/O unit.
* Extension I/O unit is that;
• Top station number = unit number � 4
• Number of occupied stations = 4 in IA Net
network.
707
Extension Input Port Start
Number at Extension I/O Unit
Slot 1 Fixed Assignment
-1 -1 to 3999
1000+(Multiples of 16)
(Invalid if a negative value is set.)
708
Extension Output Port Start
Number at Extension I/O Unit
Slot 1 Fixed Assignment
-1 -1 to 6999
4000+(Multiples of 16)
(Invalid if a negative value is set.)
709
Extension Input Port Start
Number at Extension I/O Unit
Slot 2 Fixed Assignment
-1 -1 to 3999
1000+(Multiples of 16)
(Invalid if a negative value is set.)
710
Extension Output Port Start
Number at Extension I/O Unit
Slot 2 Fixed Assignment
-1 -1 to 6999
4000+(Multiples of 16)
(Invalid if a negative value is set.)
711
Extension Input Port Start
Number at Extension I/O Unit
Slot 3 Fixed Assignment
-1 -1 to 3999
1000+(Multiples of 16)
(Invalid if a negative value is set.)
712
Extension Output Port Start
Number at Extension I/O Unit
Slot 3 Fixed Assignment
-1 -1 to 6999
4000+(Multiples of 16)
(Invalid if a negative value is set.)
713
Extension Input Port Start
Number at Extension I/O Unit
Slot 4 Fixed Assignment
-1 -1 to 3999
1000+(Multiples of 16)
(Invalid if a negative value is set.)
714
Extension Output Port Start
Number at Extension I/O Unit
Slot 4 Fixed Assignment
-1 -1 to 6999
4000+(Multiples of 16)
(Invalid if a negative value is set.)
