Chapter 4
Absolute Reset and
Absolute Battery
4.1.1 For PC Software
194
7) Once the push stopper position acquirement for all the axes is complete, the Information
window will appear. Click “OK” button.
8) Close the Push stopper position acquisition window by clicking “�” on the upper right side
of the window. Once the window is closed, the parameters start to be written automatically
to the flash ROM, and controller is rebooted by the software reset.
9) Once the controller reboot is finished, conduct the push type absolute reset on all the axes
together.
