Chapter 7
Troubleshooting
7.3 Error List (MAIN application)
416
In the panel window, the error numbers follow E in the display.
Error
No.
Error name Description, action, etc.
44A Right to use extension motion
control board axis acquirement
error �
There is no blank in the extension motion control board
axis use control area.
�
44B Right to use extension motion
control board axis already acquired
error (New acquirement failure) �
Acquirement of the right to use the extension motion
control board axis was newly tried in the condition the right
is already acquired.
�
44C Right to use extension motion
control board axis non-acquired
error (Continuous acquirement
failure) �
Failure was occurred in the continuous acquirement of the
right to use the extension motion control board axis.
�
44D Extension motion control board
axis home-return incomplete error
The home-return operation of the extension motion control
board axis is not complete.
44E Extension motion control board
operation command error at
servo-off (Main CPU detection) �
An execution of an operation command was tried while the
servo is off.
44F Error-issued extension motion
control board axis use error (Main
CPU detection) �
Use of an extension motion control board axis with an
error being issued was tried.
450 Servo-off error in extension motion
control board axis use
Servo was turned off on the extension motion control
board axis which is in use (in process).
451 Extension motion control board
direct command type error
It is a process logic error.
452 Slave driver alarm detection An alarm signal on the slave driver (SCON, ACON, PCON,
etc.) controlled by the extension motion control board or a
main CPU axis error (at main CPU axis control) was
detected.
It can be concerned that an alarm has generated on the
slave driver, the power is not turned on or cable is broken
(on pulse input and output board).
Check the condition of the slave driver or breakage of the
cable (on pulse input and output board).
453 Extension motion control board
axis home-return complete timeout
error
Home-return complete signal of the slave driver could not
be confirmed.
Check if the operation mode of the slave driver is set to
PIO Startup Forbidden or a cable is broke (on pulse input
and output board).
454 Extension motion control board
axis positioning complete timeout
error
Positioning complete signal of the slave driver could not be
confirmed.
Check if the operation mode of the slave driver is set to
PIO Startup Forbidden or a cable is broke (on pulse input
and output board).
455 Extension motion control board
synchronizing electronic cam
operation setting error
The operation setting of the synchronizing electronic can
indicated in operation 2 in XCAS command is incorrect.
456 Extension motion control board
independent electronic cam
operation setting error
The operation setting of the independent electronic can
indicated in operation 2 in XCTM command is incorrect.
O
pe
ra
tio
n-
ca
nc
el
la
tio
n
le
ve
l e
rro
rs
457 Extension motion control board
electronic shaft operation setting
error
The operation setting of the electronic shaft indicated in
operation 2 in XSFS command is incorrect.
