Chapter 7
Troubleshooting
7.3 Error List (MAIN application)
470
In the panel window, the error numbers follow E in the display.
Error
No.
Error name Description, action, etc.
E90 Core code flash-ROM status error The core program is invalid. Contact the manufacturer.
E91 Application code flash-ROM status
error
The application program is invalid. Contact the
manufacturer.
E92 Core code sum error The core program is invalid. Contact the manufacturer.
E93 Application code sum error The application program is invalid.
Contact the manufacturer.
E94 Timing limit over error (Flash erase) Error erasing the flash ROM
E95 Flash verify error (Flash erase)
Error erasing the flash ROM
E96 Flash ACK timeout (Flash erase) Error erasing the flash ROM
E97 Head sector number specification
error (Flash erase)
Error erasing the flash ROM
E98 Sector count specification error
(Flash erase)
Error erasing the flash ROM
E99 Timing limit over error (Flash write) Error writing the flash ROM
E9A Flash verify error (Flash write) Error writing the flash ROM
E9B Flash ACK timeout (Flash write) Error writing the flash ROM
E9C Write-destination offset address
error (Flash write)
Error writing the flash ROM
E9D Write-source data buffer address
error (Flash write)
Error writing the flash ROM
E9E Watchdog reset occurrence error A WDT (watchdog timer) was manually reset (error
detection).
E9F Exception occurrence error while
BL = 1 (NMI)
An exception occurred while the block bit in the CPU
status register was “1.” (NMI)
EA0 Exception occurrence error while
BL = 1 (Other than NMI)
An exception occurred while the block bit in the CPU
status register was “1.” (Other than NMI)
EA1 Bit exception reset due to
command/data TLB duplication
This reset occurs when there are multiple TLB entries
corresponding to the virtual address.
EA2 Undefined exception/interruption
error
An undefined exception/interruption occurred.
EA3 AC-power cutoff detection error An AC-power cutoff was detected.
EA4 Abnormal standby power detection
error
Abnormal standby power was detected.
EA5 Regenerative resistance
temperature error
A regenerative resistance temperature error was detected.
EA6 AC-power overvoltage error An AC-power overvoltage error was detected.
EA7 Motor-power overvoltage error A motor-power overvoltage error was detected.
EA8 FROM-write bus width error A write operation other than 32-bit long word access was
detected while writing the flash ROM.
EA9 FROM write protect error Write operation to a write-protected flash ROM area
(FRMWE bit in DEVCTR = 1) was detected.
EAA SDRAM write/read test error The SDRAM is faulty. Contact the manufacturer.
EAB Application-update SCIF
send-queue overflow error
An overflow occurred in the send queue.
EAC Servo control underrun error A servo control underrun error was detected.
EAD Boot error A FPGA boot watchdog was detected. The core program
may not be running properly.
Cold-st
art
lev
el
errors
EAE Application-update SCIF
receive-queue overflow error
Excessive data is received from outside. (Confirm that a
PC and IAI’s update tool are used to update the
application.)
