Chapter 6 Parameter
6.1 I/O Parameter (All types)
293
I/O Parameter (All types)
No. Parameter name
Default
value
(reference)
Input
range
Unit Remarks
123 Network attribute 4 0H
0H to
FFFFFFFFH
Bits 0 to 3: Ethernet TCP/IP message
communication
Selection whether to permit 0.0.0.0
(IP address of connection
destination can be ignored) as IP
address of connection destination
on server
(0: Do not permit
1: Permit (not recommended))
* Note: Number of clients that can be connected
simultaneously to one server port channel
= 1
Bits 4 to 7: EtherNet IAI Protocol
B/TCP (MANU mode)
Select existence check function
(0: Not to use, 1: Use Keep Alive)
Bits 8 to 11: EtherNet IAI Protocol
B/TCP (AUTO mode)
Select existence check function
(0: Not to use, 1: Use Keep Alive)
Bits 12 to 15: Ethernet Free-for-User Channel 31
Select existence check function
(0: Not to use, 1: Use Keep Alive)
Bits 16 to 19: Ethernet Free-for-User Channel 32
Select existence check function
(0: Not to use, 1: Use Keep Alive)
Bits 20 to 23: Ethernet Free-for-User Channel 33
Select existence check function
(0: Not to use, 1: Use Keep Alive)
Bits 24 to 27: Ethernet Free-for-User Channel 34
Select existence check function
(0: Not to use, 1: Use Keep Alive)
Bits 28 to 31: Ethernet Tracking Vision System I/F
Select existence check function
(0: Not to use, 1: Use Keep Alive)
* The connection may get cut if the mating device
is not applicable for TCP Keep Alive Function.
