Chapter 5 Special Functions
5.2 V
ision system I/F Function
262
5.2
Vision system I/F Function
This function enables the operator to save the coordinate data for work sent from the vision
system, directly on the position data.
[Refer to the separate operation manual for the Vision system I/F Function (ME0269).]
XSEL controller
Actuator
coordinate values
Vision
system
Position Data
Movement Command
