Chapter 2 Wiring
2.2.10 Extension I/O unit (Option)
103
2) System Setting
The system setting is performed for using it as extension I/O using the I/O parameter setting.
Set them to the set values as shown in the following table.
No. Parameter name
Set in
Delivery
Set
Value
Details of Parameters
602 IA Net Top Occupied Station Number 0 0
This parameter sets the Head Occupied
Station No.
603 IA Net Resizing Executed Station Number 0 0
This parameter sets the Head Occupied
Station No.
604 IA Net Final Station Number 63 7
Final station number in the same network
setting.
605 IA Net All Connected Station Patterns
(31-00)
0H 0H
This parameter sets the operation
condition of the Station No. 0 to 30.
Put the setting value to “0H” and the
setting is automatically adjusted.
606 IA Net All Connected Station Patterns
(63-32)
0H 0H
This parameter sets the operation
condition of the Station No. 32 to 63.
It is not used, so set it to “0”.
Set it to the following hexadecimal value
for each slot, based on the operation
condition of the I/O board attached to the
slot.
Not used: 0
Output port used: 1
Input port used: 2
Input port and output port used: 3
Slot Bits
1 0 to 3
2 4 to 7
3 8 to 11
4 12 to 15
705 Extension I/O Unit Use Select 0H
Refer
to the
Right
Box.
When the board has been attached on the
slot 1 and slot 2 and the both input and
output are used: Set it to “0033”.
706 Extension I/O Unit Number 1H 1H
Set the unit number of the extension I/O
unit to be connected.
