Chapter 8
Appendix
8.3 Specifications List for Connectable Single
Axis
Actuator
528
Motor
output
Lead Max. speed
Max. Acceleration/
Deceleration
Speed
Min.
Pressing
Force
Max.
Pressing
Force
Rated
Pressing
Speed
Actuator
series
Type
[W] [mm]
Mounting
direction
[mm/s] [G] [N] [N] [mm/s]
Horizontal
1200
(at to 650st)
1165
(at to 700st)
1045
(at to 750st)
940
(at to 800st)
850
(at to 850st)
770
(at to 900st)
705
(at to 950st)
1
20
Vertical
645
(at to 1000st)
595
(at to 1050st)
545
(at to 1100st)
505
(at to 1150st)
470
(at to 1200st)
440
(at to 1250st)
410
(at to 1300st)
1
– – –
Horizontal
1800
(at to 800st)
1700
(at to 850st)
1540
(at to 900st)
1410
(at to 950st)
1290
(at to 1000st)
1
ISDB
ISPDB
(Slider
Type)
L
200
400
40
Vertical
1185
(at to 1050st)
1095
(at to 1100st)
1015
(at to 1150st)
940
(at to 1200st)
875
(at to 1250st)
815
(at to 1300st)
1
– – –
20 Horizontal
1200
(at to 1200st)
1150
(at to 1300st)
1000
(at to 1400st)
950
(at to 1500st)
830
(at to 1600st)
0.4 – – –
ISDB
ISPDB
(Slider
Type)
LX
200
400
40 Horizontal
1800
(at to 1500st)
1600
(at to 1660st)
0.4 – – –
