Chapter 6 Parameter
6.1 I/O Parameter (All types)
318
I/O Parameter (All types)
No. Parameter name
Default
value
(reference)
Input
range
Unit Remarks
561 Extension Motion Control
Board 9 th Axis Control Attribute 00000000H
0H to
FFFFFFFFH
(*Same as I/O parameter No. 534)
Note: Dedicated for XSEL-R/S controller
562
Extension Motion Control
Board 9 th Axis Control Top Input
Port Number
0 0 to 3999 Note: Dedicated for XSEL-R/S controller
563
Extension Motion Control
Board 9 th Axis Control Top
Output Port Number
0 0 to 6999 Note: Dedicated for XSEL-R/S controller
564
Extension Motion Control
Board 10 th Axis Control
Attribute
00000000H
0H to
FFFFFFFFH
(*Same as I/O parameter No. 534)
Note: Dedicated for XSEL-R/S controller
565
Extension Motion Control
Board 10 th Axis Control Top
Input Port Number
0 0 to 3999 Note: Dedicated for XSEL-R/S controller
566
Extension Motion Control
Board 10 th Axis Control Top
Output Port Number
0 0 to 6999 Note: Dedicated for XSEL-R/S controller
567
Extension Motion Control
Board 11 th Axis Control
Attribute
00000000H
0H to
FFFFFFFFH
(*Same as I/O parameter No. 534)
Note: Dedicated for XSEL-R/S controller
568
Extension Motion Control
Board 11 th Axis Control Top
Input Port Number
0 0 to 3999 Note: Dedicated for XSEL-R/S controller
569
Extension Motion Control
Board 11 th Axis Control Top
Output Port Number
0 0 to 6999 Note: Dedicated for XSEL-R/S controller
570
Extension Motion Control
Board 12 th Axis Control
Attribute
00000000H
0H to
FFFFFFFFH
(*Same as I/O parameter No. 534)
Note: Dedicated for XSEL-R/S controller
571
Extension Motion Control
Board 12 th Axis Control Top
Input Port Number
0 0 to 3999 Note: Dedicated for XSEL-R/S controller
572
Extension Motion Control
Board 12 th Axis Control Top
Output Port Number
0 0 to 6999 Note: Dedicated for XSEL-R/S controller
573
Extension Motion Control
Board 13 th Axis Control
Attribute
00000000H
0H to
FFFFFFFFH
(*Same as I/O parameter No. 534)
Note: Dedicated for XSEL-R/S controller
574
Extension Motion Control
Board 13 th Axis Control Top
Input Port Number
0 0 to 3999 Note: Dedicated for XSEL-R/S controller
575
Extension Motion Control
Board 13 th Axis Control Top
Output Port Number
0 0 to 6999 Note: Dedicated for XSEL-R/S controller
576
Extension Motion Control
Board 14 th Axis Control
Attribute
00000000H
0H to
FFFFFFFFH
(*Same as I/O parameter No. 534)
Note: Dedicated for XSEL-R/S controller
577
Extension Motion Control
Board 14 th Axis Control Top
Input Port Number
0 0 to 3999 Note: Dedicated for XSEL-R/S controller
578
Extension Motion Control
Board 14 th Axis Control Top
Output Port Number
0 0 to 6999 Note: Dedicated for XSEL-R/S controller
579
Extension Motion Control
Board 15 th Axis Control
Attribute
00000000H
0H to
FFFFFFFFH
(*Same as I/O parameter No. 534)
Note: Dedicated for XSEL-R/S controller
580
Extension Motion Control
Board 15 th Axis Control Top
Input Port Number
0 0 to 3999 Note: Dedicated for XSEL-R/S controller
581
Extension Motion Control
Board 15 th Axis Control Top
Output Port Number
0 0 to 6999 Note: Dedicated for XSEL-R/S controller
582 (For expansion) 0
583 (For expansion) 0
584 (For expansion) 0
