Chapter 6 Parameter
6.1 I/O Parameter (All types)
295
I/O Parameter (All types)
No. Parameter name
Default
value
(reference)
Input
range
Unit Remarks
131 Network I/F Module 1
Own MAC address (L)
0H
Referenceonly
( HEX)
132 Network I/F Module 1
Own IP address (H)
192 1 to 255
*Setting of “0” and “127” is prohibited.
133 Network I/F Module 1
Own IP address (MH)
168 0 to 255
134 Network I/F Module 1
Own IP address (ML)
0 0 to 255
135 Network I/F Module 1
Own IP address (L)
1 1 to 254
*Setting of “0” and “255” is prohibited.
136 Network I/F Module 1
Subnet mask (H)
255 0 to 255
137 Network I/F Module 1
Subnet mask (MH)
255 0 to 255
138 Network I/F Module 1
Subnet mask (ML)
255 0 to 255
139 Network I/F Module 1
Subnet mask (L)
0 0 to 255
140 Network I/F Module 1
Default gateway (H)
0 0 to 255
141 Network I/F Module 1
Default gateway (MH)
0 0 to 255
142 Network I/F Module 1
Default gateway (ML)
0 0 to 255
143 Network I/F Module 1
Default gateway (L)
0 0 to 255
144 IAI protocol B/TCP: Own port
number (MANU mode)
64511
1025 to
65535
145 Channel 31 opened to user
(TCP/IP): Own port number
64512
1025 to
65535
146 Channel 32 opened to user
(TCP/IP): Own port number
64513
1025 to
65535
147 Channel 33 opened to user
(TCP/IP): Own port number
64514
1025 to
65535
148 Channel 34 opened to user
(TCP/IP): Own port number
64515
1025 to
65535
* Important note: Always set a unique number for
each port number.
(Duplication of port numbers is permitted only in
the IAI protocol B/TCP MANU/AUTO modes.)
149
IAI protocol B/TCP: IP address
of connection destination
(MANU mode) (H)
192 0 to 255
*Setting of “0” and “127” is prohibited.
150
IAI protocol B/TCP: IP address
of connection destination
(MANU mode) (MH)
168 0 to 255
151
IAI protocol B/TCP: IP address
of connection destination
(MANU mode) (ML)
0 0 to 255
152
IAI protocol B/TCP: IP address
of connection destination
(MANU mode) (L)
100 0 to 254
*Setting of “0” and “255” is prohibited.
153
IAI protocol B/TCP: Port
number of connection
destination (MANU mode)
64611 0 to 65535
* “0” can be set in the case of a server.
0 = Port number of connection destination is
ignored (only the IP address is checked)
* “0” cannot be set in the case of a client.
154
IAI protocol B/TCP: IP address
of connection destination
(AUTO mode) (H)
192 0 to 255
*Setting of “0” and “127” is prohibited.
155
IAI protocol B/TCP: IP address
of connection destination
(AUTO mode) (MH)
168 0 to 255
156
IAI protocol B/TCP: IP address
of connection destination
(AUTO mode) (ML)
0 0 to 255
157
IAI protocol B/TCP: IP address
of connection destination
(AUTO mode) (L)
100 0 to 254
*Setting of “0” and “255” is prohibited.
