Chapter 6 Parameter
6.1 I/O Parameter (All types)
319
I/O Parameter (All types)
No. Parameter name
Default
value
(reference)
Input
range
Unit Remarks
585 (For expansion) 0
586 (For expansion) 0
587 (For expansion) 0
588 (For expansion) 0
589 (For expansion) 0
590 (For expansion) 0
591 (For expansion) 0
592 (For expansion) 0
593 (For expansion) 0
594 (For expansion) 0
595 (For expansion) 0
596 (For expansion) 0
597 (For expansion) 0
598 (For expansion) 0
599 (For expansion) 0
600 (For expansion) 0
601 Reserved by the system
(change is prohibited)
0 0 to 4
602 IA Net Occupied Station Top
Number
0 0 to 63
603 IA Net Resizing Executed
Station Number
0 0 to 63
Station number to optimize the communication
cycle time at the IA Net startup
* Have the same value set in common for all the
controllers in the same network. The station to
execute resizing should be one in one network.
* Indicate the top station number that the
controller is to occupy.
604 IA Net Final Station Number 63 1 to 63
Final station number in the same network
* Have the same value set in common for all the
controllers in the same network.
605 IA Net All Connected Station
Patterns (31-00)
0H
0h to
FFFFFFFFh
With 0: Disconnected and 1: Connected, make the
connection conditions of Stations No. 31 to No. 0
in bit patterns and convert them into the
hexadecimal numbers to input.
606 IA Net All Connected Station
Patterns (63-32)
0H
0h to
FFFFFFFFh
With 0: Disconnected and 1: Connected, make the
connection conditions of Stations No. 63 to No. 32
in bit patterns and convert them into the
hexadecimal numbers to input.
607 IA Net error monitor 1 0 to 5
0: No Monitoring
1: Monitoring
2: Monitoring (Monitoring only on the errors related
to link error)
* There are some exception
* IA Net link error occurs when an error
condition of the network link continues for
more than what is set in IA Net network link
error check timer. (Refer to No.608 I/O
Parameter.)
608 IA Net Attribute 1 F000000H
0H to
FFFFFFFFH
Bits 0 to 7: Network Link Error Confirmation
Timer Value (10msec)
* Valid when I/O Parameter No. 607
= 1 or 2
Bits 8 to 19: System Reservation
Bits 20 to 23: Select the IA Net link error level
(0: Cold-start level
1: Message level)
Bits 24 to 31: Timeout duration (sec) for link
waiting at IA Net initializing
