Chapter 4
Absolute Reset and
Absolute Battery
4.1.1 For PC Software
157
19) Now the process for absolute reset is complete.
If a redo of the absolute reset is required, end the X-SEL PC Software once and conduct
the whole process from the beginning again.
(Note) In some actuator, the current value does not show 0mm after the absolute reset is
finished. Please note that it is not an error.
For those models other than what is listed in the table show 0 in the current value
after the absolute reset is finished.
Actuator
Lead
Current Value after Absolute Reset Complete
4
0
8
1
RCS2-SA7C (R)
16
3
6
-0.5
RCS2-SS7C (R)
12
1
10
0
20
2.5
RCS2-SS8C (R)
30
5
4
0
8
0
RCS2-RA5C (R)
16
2
�
