Chapter 6 Parameter
6.1 I/O Parameter (All types)
298
I/O Parameter (All types)
No. Parameter name
Default
value
(reference)
Input
range
Unit Remarks
204
Attribute 4 of SIO channel 1
opened to user (standard
mount)
00000000H
0H to
FFFFFFFFH
205
Attribute 5 of SIO channel 1
opened to user (standard
mount)
00000000H
0H to
FFFFFFFFH
206
Attribute 6 of SIO channel 1
opened to user (standard
mount)
00000000H
0H to
FFFFFFFFH
207
Attribute 7 of SIO channel 1
opened to user (standard
mount)
00000000H
0H to
FFFFFFFFH
208
Attribute 8 of SIO channel 1
opened to user (standard
mount)
00000000H
0H to
FFFFFFFFH
209
Attribute 9 of SIO channel 1
opened to user (standard
mount)
00000000H
0H to
FFFFFFFFH
210
Attribute 10 of SIO channel 1
opened to user (standard
mount)
00000000H
0H to
FFFFFFFFH
211
Attribute 11 of SIO channel 1
opened to user (standard
mount)
00000000H
0H to
FFFFFFFFH
212
Attribute 12 of SIO channel 1
opened to user (standard
mount)
00000000H
0H to
FFFFFFFFH
213
Attribute 1 of SIO channel 2
opened to user (standard
mount)
28100001H
0H to
FFFFFFFFH
Bits 28 to 31: Baud rate type
(0: 9.6 kbp, 1: 19.2 kbp,
2: 38.4 kbp, 3: 57.6 kbp,
4: 76.8 kbp, 5: 115.2 kbps)
* If flow control is performed, select 38.4 kbps or
below.
Use of a higher baud rate may generate an
overrun error, etc.
Bits 24 to 27: Data length (7 or 8)
Bits 20 to 23: Stop bit length (1 or 2)
Bits 16 to 19: Parity type
(0: None, 1: Odd, 2: Even)
Bits 12 to 15: Communication mode
(0: RS232C, 1: RC gateway)
* The RC gateway mode is valid only for
channel 2.
Bits 8 to 11: For future extension
Bits 4 to 7: For future extension
Bits 0 to 3: Use selection
(0: Do not use, 1: Use)
* Used on the application level.
214
Attribute 2 of SIO channel 2
opened to user (standard
mount)
00000001H
0H to
FFFFFFFFH
Bits 28 to 31: For future extension
Bits 24 to 27: Reserved by the system
Bits 20 to 23: Reserved by the system
Bits 16 to 19: Character transmission interval
(msec)
Bits 12 to 15: Communication method
(0: Full-duplex, 1: Half-duplex)
Bits 8 to 11: Send operation type in half-duplex
communication
(0: Do not check CTS-ON at send
1: Check CTS-ON at send)
Bits 0 to 7: Minimum Receive � Send
switching delay in half-duplex
communication (msec)
