Chapter 2 Wiring
2.3.1 Wiring for Power Supply Circuit
117
Parts Name Model Supplier Position to Attach
1) Noise Filter MC1320 Densei Lambda
2) Ring Core ESD-R-25 NEC TOKIN
Attach in range of
300mm or less from
controller �
3) Clamp Filter ZCAT3035-1330 TDK
4) Clamp Filter RFC-H13 Kitagawa Industries Co., Ltd.
Attach as close as
possible to controller
5) Surge Protector R·A·V-781BXZ-4 Okaya Denki
Attach at the input
terminal of noise filter
�
(1) AC Power Supply Input Connector
Connector Model Remarks
GMSTB2.5/6-STF-7.62
(PHOENIX CONTACT)
Enclosed in standard
package
Cable side PC4/5-STF-7.62 only for
XSEL-SX-NNN10040 or 12040
(PHOENIX CONTACT)
Enclosed in standard
package
GMSTB2.5/6-7.62
(PHOENIX CONTACT)
Controller side PC4/5-STF-7.62 only for
XSEL-SX-NNN10040 or 12040
(PHOENIX CONTACT)
Pin
No.
Signal name Description Applicable Wire Diameter
6 PE Protective grounding wire [Refer to Section 1.6.]
5 CP_L Control power 200 VAC, phase L
4 CP_N Control power 200 VAC, phase N
0.75mm 2 (AWG18)
3 MP_R Motor power 200 VAC, phase R
2 MP_S Motor power 200 VAC, phase S
1 MP_T Motor power 200 VAC, phase T
2mm 2 (AWG14)
PE
T
S MP
PWR
N
R
L
CP
(2) Brake Power Connector
Connector Model Remarks
Cable side
MC1.5/2-ST-3.5
(PHOENIX CONTACT)
Enclosed in standard
package
Controller side
MC1.5/2-G-3.5
(PHOENIX CONTACT)
Pin No. Signal name Description Applicable wire
+24V 24V Power Input
0V 24V Power Ground
0.14 to 1.5mm 2
(AWG28 to AWG16)
BK PWR
+24V
+
-
0V
