Chapter 3 Operation
3.2 I/O Ports
143
(1) I/O map
The factory-set I/O port numbers and functions of the XSEL controller are shown below.
The functions of the I/O port can be changed using the parameter setting.
[Refer to 2.2.7 PIO Circuit and Chapter 6. Parameters]
Port
number
Function
Port
number
Function
000 Program start 300 Alarm output
001 General-purpose input 301 Ready output
002 General-purpose input 302 Emergency stop output
003 General-purpose input 303 General-purpose output
004 General-purpose input 304 General-purpose output
005 General-purpose input 305 General-purpose output
006 General-purpose input 306 General-purpose output
007
Program specification
(PRG No. 1)
307 General-purpose output
008
Program specification
(PRG No. 2)
308 General-purpose output
009
Program specification
(PRG No. 4)
309 General-purpose output
010
Program specification
(PRG No. 8)
310 General-purpose output
011
Program specification
(PRG No. 10)
311 General-purpose output
012
Program specification
(PRG No. 20)
312 General-purpose output
013
Program specification
(PRG No. 40)
313 General-purpose output
014 General-purpose input 314 General-purpose output
015 General-purpose input 315 General-purpose output
Input
� �
Output
� �
(Note) The numbers of I/O ports are as follows:
Inputs : 000 to 299 (300 points max.)
Outputs : 300 to 599 (300 points max.)
