Chapter 6 Parameter
6.1 I/O Parameter (All types)
312
I/O Parameter (All types)
No. Parameter name
Default
value
(reference)
Input
range
Unit Remarks
460
User-Defined Memory Block
Attribute 1 (Memory Block No.
1)
0
0H to
FFFFFFFFH
Bits 0 to 3: Applicable data type
(0 = Disable, 1 = Input and output,
plugs)
Bits 4 to 7: User-defined address construction
type
(0 = No H/L Byte Swap Assignment
1 = H/L Byte Swap Assignment)
Bits 8 to 11: Double word data type
(0 = indicated word address number
n: low-order 16 bits, No. n+1: host 16
bits
1 = indicated word address number
n: host-order 16 bits, No. n+1: low 16
bits)
461
User-Defined Memory Block
Attribute 2 (Memory Block No.
1)
0 0 to 65535
Applicable data top number
* Indicate with the input and output plug numbers
when the data type = input and output, plugs
462
User-Defined Memory Block
Attribute 3 (Memory Block No.
1)
0 0 to 65535
Number of applicable data
* When the data type = input and output, plugs,
Multiples of 16
463
User-Defined Memory Block
Attribute 4 (Memory Block No.
1)
0 0 to 65535 Top user-defined word address in memory block
464
User-Defined Memory Block
Attribute 1 (Memory Block No.
2)
0
0H to
FFFFFFFFH
(Same as I/O parameter No. 460)
465
User-Defined Memory Block
Attribute 2 (Memory Block No.
2)
0 0 to 65535 (Same as I/O parameter No. 461)
466
User-Defined Memory Block
Attribute 3 (Memory Block No.
2)
0 0 to 65535 (Same as I/O parameter No. 462)
467
User-Defined Memory Block
Attribute 4 (Memory Block No.
2)
0 0 to 65535 (Same as I/O parameter No. 463)
468
User-Defined Memory Block
Attribute 1 (Memory Block No.
3)
0
0H to
FFFFFFFFH
(Same as I/O parameter No. 460)
469
User-Defined Memory Block
Attribute 2 (Memory Block No.
3)
0 0 to 65535 (Same as I/O parameter No. 461)
470
User-Defined Memory Block
Attribute 3 (Memory Block No.
3)
0 0 to 65535 (Same as I/O parameter No. 462)
471
User-Defined Memory Block
Attribute 4 (Memory Block No.
3)
0 0 to 65535 (Same as I/O parameter No. 463)
472
User-Defined Memory Block
Attribute 1 (Memory Block No.
4)
0
0H to
FFFFFFFFH
(Same as I/O parameter No. 460)
473
User-Defined Memory Block
Attribute 2 (Memory Block No.
4)
0 0 to 65535 (Same as I/O parameter No. 461)
474
User-Defined Memory Block
Attribute 3 (Memory Block No.
4)
0 0 to 65535 (Same as I/O parameter No. 462)
475
User-Defined Memory Block
Attribute 4 (Memory Block No.
4)
0 0 to 65535 (Same as I/O parameter No. 463)
476
User-Defined Memory Block
Attribute 1 (Memory Block No.
5)
0
0H to
FFFFFFFFH
(Same as I/O parameter No. 460)
477
User-Defined Memory Block
Attribute 2 (Memory Block No.
5)
0 0 to 65535 (Same as I/O parameter No. 461)
