Chapter 1 Specifications Check
1.1 Product Check
1.1.1 Components (Excluding Options) 1.1.2
Teaching
Tool (Optional)
31
Chapter 1 Specifications Check
1.1 Product Check
The standard configuration of this product is comprised of the following parts.
If you find any faulty or missing parts, contact your local IAI distributor.
1.1.1 Components (Excluding Options)
Quantity
No.
Item
Model
R/RX/RXD S/SX/SXD
1
Controller Main Body Refer to “How to read the model plate”, “How to read the
model”.
�
Accessories
�
2
System I/O Plug
FMC1.5/9-ST-3.5 (Manufacturer: Phoenix Contact)
2
2
GMSTB2.5/6-STF-7.62 (Manufacturer: Phoenix Contact)
1
1
3
AC Power Plug
In the case of
XSEL-SX-NNN10040 or 12040
PC4/6- STF-7.62 (Manufacturer: Phoenix Contact)
-
4
Brake Power Input
Plug
MC1.5/2-ST-3.5 (Manufacturer: Phoenix Contact)
1
1
5
Dummy Plug
DP-2
-
1
6
First Step Guide
1
1
7
Operation Manual
(DVD)
1
1
8
Safety Guide
1
1
�
�
1.1.2 Teaching Tool (Optional)
The PC software or teaching pendant is necessary to perform setup operations such as
position and parameter settings through teaching or other means.
Use either of them.
Applicable controllers
No.
Item
Model
R/RX/RXD S/SX/SXD
1
PC Software (with RS232C Cable + Emergency Stop Box)
IA-101-X-MW
�
�
2
PC Software (with USB Conversion Adapter + RS232C
Cable + Emergency Stop Box)
IA-101-X-USBMW
�
�
3
PC Software (Safety Categories 4 compliance cable +
Emergency Stop Box)
IA-101-XA-MW
�
�
4
Teaching pendant
SEL-T
�
�
5
Teaching pendant (with deadman switch)
SEL-TD
�
�
6
Teaching pendant (with deadman switch + TP adapter
(IA-LB-TG))
SEL-TG
�
�
7
Teaching pendant
IA-T-X
�
�
8
Teaching pendant (with deadman switch)
IA-T-XD
�
�
�
