Chapter 6 Parameter
6.1 I/O Parameter (All types)
300
I/O Parameter (All types)
No. Parameter name
Default
value
(reference)
Input
range
Unit Remarks
225 NetworkI/FModule Controller 0H
0H to
FFFFFFFFH
Bits 0 to 3: Type of Network I/F Module Control 1
(0: Not mounted,
1: CC-Link,
2: DeviceNet,
3: Profibus,
4 to 5: System Reservation,
6: EtherCAT,
7: EtherNet/IP)
Bits 4 to 7: Type of Network I/F Module Control 2
(0: Not mounted,
1: CC-Link,
2: DeviceNet,
3: Profibus,
4 to 7: System Reservation)
Bits 8 to 11: Reserved by the system (change is
prohibited)
226 Network I/F Module 1 Node
Address
0
0 to
999999999
Settable Range
• At CC-Link: 1 to 64
• At DeviceNet: 0 to 63
• At Profibus: 0 to 125
• At EtherCAT: 0 to 127
227 Network I/F Module 1 Baud
rate
0 0 to 9
• At CC-Link:
(0: 156kbps, 1: 625kbps, 2: 2.5Mbps,
3: 5Mbps, 4: 10Mbps)
• At DeviceNet:
(0: 125kbps, 1: 250kbps, 2: 500kbps)
• At EtherNet/IP:
(0: Autonegotiation, 1: 10Mbps (Half-Duplex),
2: 10Mbps (Full-Duplex), 3: 100Mbps
(Half-Duplex), 4: 100Mbps (Full-Duplex))
* Setting establishment not necessary for
Profibus and EtherCAT
228 (For expansion) 0
229 (For expansion) 0
230 (For expansion) 0
231 No. of Network I/F Module 2
Remote Input Ports
0 0 to 256 Multiples of 8
232 No. of Network I/F Module 2
Remote Output Ports
0 0 to 256 Multiples of 8
233
Network I/F Module 2
Extension Input Port Start
Number Fixed Assignment
-1 -1 to 3999
0+(Multiples of 8)(0 to 299)
1000+(Multiples of 8)(1000 to 3999)
(Invalid if a negative value is set.)
* No. 0 to 299 are to be applicable in V0.10 and
later of CPU application area.
234
Network I/F Module 2
Extension Output Port Start
Number Fixed Assignment
-1 -1 to 6999
300+(Multiples of 8)(300 to 599)
4000+(Multiples of 8)(4000 to 6999)
(Invalid if a negative value is set.)
* No. 300 to 599 are to be applicable in V0.10
and later of CPU application area.
235 Network I/F Module 2 error
monitor
1 0 to 5
0: No Monitoring
1: Monitoring
*There are some exception
236 System Reservation 0H
0H to
FFFFFFFFH
237 Network I/F Module 2 Node
Address
0
0 to
999999999
Settable Range
• At CC-Link: 1 to 64
• At DeviceNet: 0 to 63
• At Profibus: 0 to 125
238 Network I/F Module 2 Baud
rate
0 0 to 9
• At CC-Link:
(0: 156kbps, 1: 625kbps, 2: 2.5Mbps,
3: 5Mbps, 4: 10Mbps)
• At DeviceNet:
(0: 125kbps, 1: 250kbps, 2: 500kbps)
* Setting establishment not necessary for
Profibus
