Chapter 6 Parameter
6.10 Parameter Setting (Applied)
400
6.10.28 Want to Monitor Variables without Connecting a Teaching Tool
Global integer variables can be displayed on the panel window.
Positive integers of 1 to 999 can be displayed.
Parameter No. Set Value Description
Other parameter No.49 2
Other parameter No.50
Variable number of the
global integer variable
to be monitored
If parameters are entered and written to the flash ROM and then a software reset (restart) is
performed, the content of the global integer variable displayed instead of “ready status
display”/“current program number display.” The far left segment shows “U.”
Display example
