Chapter 6 Parameter
6.7 Other Parameters (All types)
381
Other Parameters (All types)
No. Parameter name
Default
value
(reference)
Input range Unit Remarks
36 PC/TP data protect setting
(Program)
0H
0H to
FFFFFFFFH
Bits 0 to 3: Protect type
(0: Read/write, 1: Read only,
2: No read/write)
Bits 4 to 7: Protect release method
(0: Special operation)
Bits 8 to 11: Protect range maximum number
(1’s place, BCD)
Bits 12 to 15: Protect range maximum number
(10’s place, BCD)
Bits 16 to 19: Protect range minimum number
(1’s place, BCD)
Bits 20 to 23: Protect range minimum number
(10’s place, BCD)
* Referenced by the PC/TP
* Data cannot be protected for program Nos. 100
to 128 which are outside the allowable setting
range (these programs are not covered by the
data protection specification.)
37 PC/TP data protect setting
(Position)
0H
0H to
FFFFFFFFH
Bits 0 to 3: Protect type (0: Read/write, 1:
Read only, 2: No read/write)
Bits 4 to 7: Protect release method (0: Special
operation)
Bits 8 to 11: Protect range maximum number
(10’s place, BCD)
Bits 12 to 15: Protect range maximum number
(100’s place, BCD)
Bits 16 to 19: Protect range maximum number
(1000’s place, BCD)
Bits 20 to 23: Protect range minimum number
(10’s place, BCD)
Bits 24 to 27: Protect range minimum number
(100’s place, BCD)
Bits 28 to 31: Protect range minimum number
(1000’s place, BCD)
* The value in the 1’s place is considered “0” for
both the protect range maximum/minimum
numbers.
* Referenced by the PC/TP
* Data cannot be protected for program Nos. 9991
to 20000 which are outside the allowable setting
range (these programs are not covered by the
data protection specification.)
38 PC/TP data protect setting
(Symbol, parameter)
0H
0H to
FFFFFFFFH
Bits 0 to 3: Protect type (Parameter)
(0: Read/write, 1: Read only,
2: No read/write)
Bits 4 to 7: Protect release method
(Parameter)
(0: Special operation)
Bits 8 to 11: Protect type (Symbol)
(0: Read/write, 1: Read only,
2: No read/write)
Bits 12 to 15: Protect release method (Symbol)
(0: Special operation)
* Referenced by the PC/TP
