Chapter 7
Troubleshooting
7.3 Error List (MAIN application)
436
In the panel window, the error numbers follow E in the display.
Error
No.
Error name Description, action, etc.
801 SCIF overrun status (IAI protocol
reception)
Communication failure.
Check for noise, connected equipment and communication
setting.
802 SCIF receive ER status (IAI
protocol reception)
Communication failure.
Check for noise, shorted/disconnected communication
cable, connected equipment and communication setting.
This error will also occur when establishing communication
with the PC/TP wrongly connected to SIO-CH1 being
opened to the user.
803 Receive timeout status (IAI protocol
reception)
The transfer interval after the first received byte is too long.
Possible causes include disconnected communication
cable and error in the connected equipment.
804 SCIF overrun status (SEL
reception)
Communication failure.
Check for noise, connected equipment and communication
setting.
805 SCIF receive ER status (SEL
reception)
Communication failure.
Check for noise, shorted/disconnected communication
cable, connected equipment and communication setting.
806 SCIF receive ER status due to
other factor (SEL reception)
Communication failure.
Take the same action specified for error No. 804 or 805.
807 Drive-source cutoff relay ER status The motor-drive power ON status remains ON even when
the drive source is cut off.
The drive-source cut-off relay contacts may have been
melted.
808 Power OFF status during slave
parameter write
The power was turned off while writing slave parameters.
(This error can be detected only when a backup battery is
used.)
809 Power OFF status during data write
to flash ROM
The power was turned off while writing data to the flash
ROM. (This error can be detected only when a backup
battery is used.)
80A Expanded-SIO overrun status (SEL
reception)
Communication failure.
Check for noise, connected equipment and communication
setting.
80B Expanded-SIO parity ER status
(SEL reception)
Communication failure.
Check for noise, shorted/disconnected communication
cable, connected equipment and communication setting.
80C Expanded-SIO framing ER status
(SEL reception)
Communication failure.
Check for noise, shorted/disconnected communication
cable, connected equipment and communication setting.
80D Expanded-SIO receive ER status
due to other factor (SEL reception)
Communication failure.
Take the same action specified for error No. 80A, 80B or
80C.
80E Expanded-SIO receive buffer
overflow status (SEL reception)
The receive buffer overflowed.
Excessive data was received from outside.
80F Ethernet control status 1 Ethernet control information (for analysis)
810 Ethernet control status 2 Ethernet control information (for analysis)
811 Maintenance information 1 Maintenance information (for analysis)
812 Maintenance information 2 Maintenance information (for analysis)
813 Maintenance information 3 Maintenance information (for analysis)
814 Maintenance information 4 Maintenance information (for analysis)
815 Maintenance information 5 Maintenance information (for analysis)
S
ec
re
t l
ev
el
e
rr
or
s
81A Mounted-SIO overrun status (SEL
reception)
Communication failure.
Check for noise, connected equipment and communication
setting.
