Chapter 6 Parameter
6.1 I/O Parameter (All types)
307
I/O Parameter (All types)
No. Parameter name
Default
value
(reference)
Input
range
Unit Remarks
338 Output function selection 307
(area 2)
0 0 to 5
0: General-purpose output
1: 3 rd axis in-position output (turned OFF when
pressing missed)
2: Axis 3 servo currently-ON output
(system-monitored task output)
3: System Reservation
339 Output function selection 308
(area 2)
0 0 to 5
0: General-purpose output
1: 4 th axis in-position output (turned OFF when
pressing missed)
2: Axis 4 servo currently-ON output
(system-monitored task output)
3: System Reservation
340 Output function selection 309
(area 2)
0 0 to 5
0: General-purpose output
1: 5 th axis in-position output (turned OFF when
pressing missed)
2: Axis 5 servo currently-ON output
(system-monitored task output)
3: System Reservation
341 Output function selection 310
(area 2)
0 0 to 5
0: General-purpose output
1: 6 th axis in-position output (turned OFF when
pressing missed)
2: Axis 6 servo currently-ON output
(system-monitored task output)
3: System Reservation
342 Output function selection 311
(area 2)
0 0 to 5
0: General-purpose output
1: 7 th axis in-position output (turned OFF when
pressing missed)
2: Axis 7 servo currently-ON output
(system-monitored task output)
3: System Reservation
343 Output function selection 312
(area 2)
0 0 to 5
0: General-purpose output
1: 8 th axis in-position output (turned OFF when
pressing missed)
2: Axis 8 servo currently-ON output
(system-monitored task output)
3: System Reservation
344 Output function selection 313
(area 2)
0 0 to 5
0: General-purpose output
1: System Reservation
345 Output function selection 314
(area 2)
0 0 to 5
0: General-purpose output
1: Absolute-data backup battery voltage at
low-voltage warning level or below (All axes are
checked for generation of this alarm. If an
abnormal level is detected, the system will be
latched until a power-ON reset or software reset
is performed.)
346 Output function selection 315
(area 2)
0 0 to 5
0: General-purpose output
347 (For expansion) 0
348 (For expansion) 0
349 (For expansion) 0
350 (For expansion) 0
