8.3 Specifications List for Connectable Single
Axis
Actuator
529
Motor
output
Lead Max. speed
Max. Acceleration/
Deceleration
Speed
Min.
Pressing
Force
Max.
Pressing
Force
Rated
Pressing
Speed
Actuator
series
Type
[W] [mm]
Mounting
direction
[mm/s] [G] [N] [N] [mm/s]
SXMS-A – – –
SXMS-I
60 12 Horizontal 720 0.8
– – –
SXMM-A – – –
SXMM-I
60 12 Horizontal 720 0.8
– – –
SZMS-A – – –
SZMS-I
60 12 Vertical 600 0.7
– – –
SZMM-A – – –
NS
(Absolute
type only)
SZMM-I
60 12 Vertical 600 0.7
– – –
30 1800 1.0 – – –
MXMS 200
20
Horizontal
1200 0.8 – – –
30 1800 1.0 – – –
MXMM 200
20
Horizontal
1200 0.8 – – –
30 1800 0.3 – – –
MXMXS 200
20
Horizontal
1200 0.3 – – –
MZMS 200 20 Vertical 1000 0.5 – – –
MZMM 200 20 Vertical 1000 0.5 – – –
40 Horizontal 2400 1.0 – – –
LXMS 400
20 Horizontal 1300 1.0 – – –
40 Horizontal 2400 1.0 – – –
LXMM 400
20 Horizontal 1300 1.0 – – –
40 Horizontal 2400 0.3 – – –
LXMXS 400
20 Horizontal 1300 0.3 – – –
LZMS 400 20 Vertical 1000 0.8 – – –
NS
LZMM 400 20 Vertical 1000 0.8 – – –
60 Horizontal 0.3 – – –
SA
100
35
Horizontal
1750
0.3 – – –
200 Horizontal – – –
IF
MA
400
35
Horizontal
1750 0.3
– – –
60 Horizontal 0.3 – – –
NM
100
25
Horizontal
1250
0.3 – – –
100 Horizontal 0.3 – – –
WM
200
25
Horizontal
1250
0.3 – – –
LM 400 25 Horizontal 1250 0.3 – – –
FS
HM 400 40 Horizontal 2000 0.3 – – –
