Intel ® 413808 and 413812 I/O Controllers in TPER Mode
October 2007 Developer’s Manual
Order Number: 317805-001US 249
Address Translation Unit (PCI Express)—Intel
®
413808 and 413812
Figure 27. Outbound Address Translation Windows
ATU Outbound Memory
Translation Windows
(Default)
ATU Outbound I/O Cycle
Translation Window
(default)
1 0000 0000H
2 0000 0000H
0 0000 0000H
1 FFFF FFFFH
2 FFFF FFFFH
Memory Window 0
Memory Window 1
Code / Data
I/O Window
4 Gbytes
64 Kbytes
External Memory
Note: These memory section defaults can be modified by programming the
OUMBAR0-3 registers prior to enabling outbound translation in the ATUCR.
3 0000 0000H
3 FFFF FFFFH
Memory Window 2
4 0000 0000H
4 FFFF FFFFH
Memory Window 3
0 FFFD 0000H
0 FFFD FFFFH
0 FFFC FFFFH
B6197-01
