Lenze 9400 - Manual (Page 735)

Lenze · Servo-Inverter 9400 HighLine · Reference manual · DMS 10.0 EN · 11/2013 · TD05/06
735
14 Parameter reference
14.2 Parameter list | C00022
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00022
C00034
C00050
C00051
C00052
Parameter | Name:
C00022 | Maximum current
Data type: UNSIGNED_32
Index: 24553
d
= 5FE9
h
Note:
• To avoid that the motor starts unintentionally without adjusting the plant data, the maximum current in the
Lenze setting is set to "0 A"!
• The upper limit value is the maximum device current (see display in C00789 ).
• In the case of an offline parameter setting or when exchanging the memory module between different 9400
HighLine device types, always check the setting of this parameter and adapt it, if required, to prevent a
parameter error after the parameter set download or module change!
• Also check the threshold set for the maximum motor current monitoring ( C00620 ).
Setting range (min. value | unit | max. value) Lenze setting
0.00 A 21474836.47 0.00 A
 Read access  Write access  CINH  PLC STOP  No transfer Scaling factor: 100
Parameter | Name:
C00034 | Config. analog input 1
Data type: UNSIGNED_32
Index: 24541
d
= 5FDD
h
Selection list (Lenze setting printed in bold)
0 -10 ... +10 V
1 -20...-4 mA, +4...+20 mA
2 -20 ... +20 mA
 Read access  Write access  CINH  PLC STOP  No transfer Scaling factor: 1
Parameter | Name:
C00050 | Speed setpoint [rpm]
Data type: INTEGER_32
Index: 24525
d
= 5FCD
h
Display range (min. value | unit | max. value)
-480000 rpm 480000
Subcodes Info
C00050/1 Speed setpoint 1 [rpm]
C00050/2 Speed setpoint 2 [rpm]
 Read access  Write access  CINH  PLC STOP  No transfer Scaling factor: 1
Parameter | Name:
C00051 | Actual speed [rpm]
Data type: INTEGER_32
Index: 24524
d
= 5FCC
h
Display range (min. value | unit | max. value)
-480000 rpm 480000
 Read access  Write access  CINH  PLC STOP  No transfer Scaling factor: 1
Parameter | Name:
C00052 | Motor voltage
Data type: UNSIGNED_32
Index: 24523
d
= 5FCB
h
Display range (min. value | unit | max. value)
0 V 2147483647
 Read access  Write access  CINH  PLC STOP  No transfer Scaling factor: 1
