4.2.24
Calculate inv. characteristic
If a motor of a third-party manufacturer with unknown motor parameters is driven by the
controller, the
= "71: Determine inverter characteristic" device command can be used to
determine the so-called "Inverter error characteristic" for optimising the inverter switching
performance.
Tip!
Detailed information about the determination of the inverter error characteristic can be
found in the chapter "Motor interface" in the subchapter "
From software version V4.0:
If the inverter error characteristic cannot be determined by
means of this device command, or if the results of the determination are incorrect, the
device command "
" can be used to load a characteristic typical
of the device.
Possible status displays for this device command
Related device commands
Status (
Meaning
4687106 Device command in process
4653056 Device command executed successfully
4653057 General fault
4692754 The calculation of the inverter characteristic cannot be started since the current controller
test mode is active.
4692755 The calculation of the inverter characteristic cannot be started since the V/f test mode is
active.
4692756 The calculation of the inverter characteristic cannot be started since the pole position
identification is active.
4692757 Calculation of the inverter characteristic has been aborted.
4692758 Calculation of the inverter characteristic has been interrupted by error.
4692789 Determined inverter error characteristic exceeds internal limits.
• This situation can for instance occur if the motor power is very much lower than the
device power.
•
This error message is only available from software version V5.0 onwards.
