Page 297
Lenze · Servo-Inverter 9400 HighLine · Reference manual · DMS 10.0 EN · 11/2013 · TD05/06
297
9
"CAN on board" system bus
9.2
Possible settings by DIP switch
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
9.2.2
Setting the baud rate
The baud rate can be set via code
or with the DIP switches a to d:
Tip!
The baud rate resulting from the setting of the DIP switches at the last mains switching is
displayed in
Switch positions
Baud rate
d
c
b
a
OFF
ON
ON
OFF
10 kbps
OFF
ON
OFF
ON
20 kbps
OFF
OFF
ON
ON
50 kbps
OFF
OFF
ON
OFF
125 kbps
OFF
OFF
OFF
ON
250 kbps
OFF
OFF
OFF
OFF
500 kbps
ON
ON
ON
OFF
800 kbps
OFF
ON
OFF
OFF
1 Mbps
OFF
ON
ON
ON
Automatic recognition
Note!
Switch the voltage supply of the basic device off and then on again to activate altered
settings.
