8 I/O terminals
8.1 Overview
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
8 I/O terminals
This chapter provides information about options for parameter setting and configuration of the
controller input and output terminals.

Tip!
Information on wiring the terminals can be found in the Mounting Instructions for the
controller!
8.1 Overview
Front view Terminal assignment Info
 "State bus" monitoring function ( 283)
 Analog inputs ( 274)
 Analog outputs ( 277)
 Digital outputs ( 281)
 Digital inputs ( 279)
 Touch probe detection ( 285)
GE
24E
SB
X2
X3
GA
AO1
AO2
A1+
A1-
A1-
A1R
A2+
A2-
GO
24O
DO1
DO2
DO3
DO4
X4
X5
GI
RFR
DI1
DI2
DI3
DI4
DI5
DI6
DI7
DI8
