16 Parameter reference
16.2 Parameter list | C01068
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C01068
C01069
Parameter | Name:
C01068 | L_SwitchPoint_1: Invert
Data type: UNSIGNED_16
Index: 23507
d
= 5BD3
h
From version 12.00.00
Setting range (min. hex value | max. hex value)
0x0000 0xFFFF
Value is bit-coded:
Bit 0 Invert Output1
Bit 1 Invert Output2
Bit 2 Invert Output3
Bit 3 Invert Output4
Bit 4 Reserved
Bit 5 Reserved
Bit 6 Reserved
Bit 7 Reserved
Bit 8 Reserved
Bit 9 Reserved
Bit 10 Reserved
Bit 11 Reserved
Bit 12 Reserved
Bit 13 Reserved
Bit 14 Reserved
Bit 15 Reserved
Subcodes Lenze setting Info
C01068/1 0x0000 L_SwitchPoint_1 : Inversion of outputs
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT
Parameter | Name:
C01069 | L_DFSET_1: Ramp settings
Data type: UNSIGNED_16
Index: 23506
d
= 5BD2
h
From version 12.00.00
Setting range
(min. value | unit | max. value)
0 Incr./ms 32767
Subcodes Lenze setting Info
C01069/1 10 incr./ms L_DFSET_1 : Ramp SpeedTrim
C01069/2 100 incr./ms L_DFSET_1 : Ramp angle compensation
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
