16 Parameter reference
16.2 Parameter list | C00841
938
Lenze · 8400 protec HighLine · Reference manual · DMS 3.0 EN · 03/2013 · TD05
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00841
C00840/105 Reserved
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00840 | 16-bit inputs I/O level [%]
Data type: INTEGER_16
Index: 23735
d
= 5CB7
h
Parameter | Name:
C00841 | 16-bit inputs I/O level
Data type: UNSIGNED_16
Index: 23734
d
= 5CB6
h
Decimal/hexadecimal/bit coded display of 16 bit input values of various blocks of the I/O level
Display area
(min. hex value | max. hex value)
0x0000 0xFFFF
Value is bit-coded:
Bit 0 Active
... ...
Bit 15 Active
Subcodes Info
C00841/1 Reserved
C00841/2 LP_CanOut1 : wState
C00841/3 LP_CanOut1 : wOut2
C00841/4 LP_CanOut1 : wOut3
C00841/5 LP_CanOut1 : wOut4
C00841/6 LP_CanOut2 : wOut1
C00841/7 LP_CanOut2 : wOut2
C00841/8 LP_CanOut2 : wOut3
C00841/9 LP_CanOut2 : wOut4
C00841/10 LP_CanOut3 : wOut1
C00841/11 LP_CanOut3 : wOut2
C00841/12 LP_CanOut3 : wOut3
C00841/13 LP_CanOut3 : wOut4
C00841/14 LS_DisFree_a : nDis1_a
C00841/15 LS_DisFree_a : nDis2_a
C00841/16 LS_DisFree_a : nDis3_a
C00841/17 LS_DisFree_a : nDis4_a
C00841/18 LS_DisFree : wDis1
C00841/19 LS_DisFree : wDis2
C00841/20 LS_DisFree : wDis3
C00841/21 LS_DisFree : wDis4
C00841/22 LP_MciOut : wState
C00841/23 LP_MciOut : wOut2
C00841/24 LP_MciOut : wOut3
C00841/25 LP_MciOut : wOut4
C00841/26 LP_MciOut : wOut5
C00841/27 LP_MciOut : wOut6
C00841/28 LP_MciOut : wOut7
C00841/29 LP_MciOut : wOut8
C00841/30 LP_MciOut : wOut9
