16 Parameter reference
16.2 Parameter list | C01230
1002
Lenze · 8400 protec HighLine · Reference manual · DMS 3.0 EN · 03/2013 · TD05
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C01230
C01231
Parameter | Name:
C01230 | Manual jog: Setting
Data type: UNSIGNED_8
Index: 23345
d
= 5B31
h
Settings for "Manual jog" mode
 Manual jog
Setting range (min. hex value | max. hex value) Lenze setting
0x00 0xFF 0x00 (decimal: 0)
Value is bit-coded: ( = bit set) Info
Bit 0  Breakpoints 1..4 on "1" ≡ approach of the parameterised breakpoint in
manual jog direction
Bit 1  Time-based start of 2nd speed "1" ≡ Automatic change-over to second manual speed
after the wating time set in C01235/1 .
Bit 2  HW limit switch on "1" ≡ Travel range monitoring via hardware limit switch
is active. The error response can be parameterised in
C00595/1 and C00595/2 .
Bit 3  SW limit switch on "1" ≡ Travel range monitoring via parameterised
software limit positions is active. The error response can
be parameterised in C00595/3 and C00595/4 .
Bit 4  Reserved
Bit 5  Reserved
Bit 6  Reserved
Bit 7  Position controller off
"1" ≡ Position controller is deactivated. Thus, the
compensation of the following error is switched off.
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT
Parameter | Name:
C01231 | MCK: Manual jog speeds
Data type: INTEGER_32
Index: 23344
d
= 5B30
h
Manual jog speeds
 Manual jog
Setting range (min. value | unit | max. value)
-214748.3647 units/s 214748.3647
Subcodes Lenze setting Info
C01231/1 360.0000 units/s Manual jog: speed 1
• Regular manual speed
C01231/2 720.0000 units/s Manual jog: Speed 2
• Second manual speed (can be activated via MCK
control word)
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 10000
