Lenze · 8400 protec HighLine · Reference manual · DMS 3.0 EN · 03/2013 · TD05
557
9 Diagnostics & error management
9.3 Drive diagnostics via the integrated 7-segment display
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
9.3 Drive diagnostics via the integrated 7-segment display
The controller comes with an integrated 7-segment display which can show 4 or 5 characters.
[9-2] 7-segment display, 5 characters (S1 .... S5)
The display has three different modes:
1. Automatic display
• When the controller is switched on, the parameter saved as status value 1 is displayed.
2. Manual operation display
• For triggering the controller in manual operation.
3. Message display
• For errors or warnings.
• This display has the highest priority and overrides the two other modes.
Detailed information on the different modes can be found in the following sections.
Key Function
T1 Operator button for status display of subordinated devices (in preparation)
T2 Operator button for browsing the status values S1 ... S5 or if several messages are present at
the same time.
8 8 8 8 8 . . . . .
T1
S1 S2 S3 S4 S5
T2
