Parameter reference

15.3

Table of attributes

_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _

Active Product

Linear value

21666

54A2

E

1

UNSIGNED_32

1

Product Name

String

21665

54A1

E

1

VISIBLE_STRING [16]

Product Choice

Linear value

21664

54A0

E

1

UNSIGNED_32

1

Number of products

Linear value

21663

549F

E

1

UNSIGNED_32

1

Number of curve tracks

Linear value

21656

5498

E

1

UNSIGNED_32

1

Cam Track Choice

Linear value

21655

5497

E

1

UNSIGNED_32

1

Cam Track Type

Selection list

21654

5496

E

1

UNSIGNED_32

1

Number of Cam Data Points

Linear value

21653

5495

E

1

UNSIGNED_32

1

Cam Data Point Choice

Linear value

21652

5494

E

1

UNSIGNED_32

1

Change Cam Data Point X

Linear value

21651

5493

E

1

INTEGER_32

10000

Change Cam Data Point Y

Linear value

21650

5492

E

1

INTEGER_32

10000

Change Cam Data Point M

Linear value

21649

5491

E

1

INTEGER_32

100

Auto Inc Cam Data Points

Selection list

21648

5490

E

1

UNSIGNED_32

1

Number of Cont Tracks

Linear value

21636

5484

E

1

UNSIGNED_32

1

Cont Track Choice

Linear value

21635

5483

E

1

UNSIGNED_32

1

Cont Type

Selection list

21634

5482

E

1

UNSIGNED_32

1

Number of Cont Data Points

Linear value

21633

5481

E

1

UNSIGNED_32

1

Cont Data Point Choice

Linear value

21632

5480

E

1

UNSIGNED_32

1

Cont Pos X0

Linear value

21631

547F

E

1

INTEGER_32

10000

Cont Pos X1

Linear value

21630

547E

E

1

INTEGER_32

10000

Cont Time

Linear value

21629

547D

E

1

UNSIGNED_32

10000

Number of Position Tracks

Linear value

21616

5470

E

1

UNSIGNED_32

1

Pos Track Choice

Linear value

21615

546F

E

1

UNSIGNED_32

1

Number of Pos Data Points

Linear value

21613

546D

E

1

UNSIGNED_32

1

Pos Data Point Choice

Linear value

21612

546C

E

1

UNSIGNED_32

1

Change Pos Data Point X

Linear value

21611

546B

E

1

INTEGER_32

10000

Change Pos Data Point Y

Linear value

21610

546A

E

1

INTEGER_32

10000

Code

Name

Type

Index

Data

dec

hex

DS

DA

DT

Factor

CINH

Grayed out = display parameter (read access only)
