15 Parameter reference
15.2 Parameter list | C02923
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C02923
C02924
C02925
C02926
C02927
Parameter | Name:
C02923 | Cam Data Point Choice
Data type: UNSIGNED_32
Index: 21652
d
= 5494
h
 Changing cam data via parameterisation
Setting range (min. value | unit | max. value) Lenze setting
0 65535 0
 Read access  Write access  CINH  PLC STOP  No transfer Scaling factor: 1
Parameter | Name:
C02924 | Change Cam Data Point X
Data type: INTEGER_32
Index: 21651
d
= 5493
h
 Changing cam data via parameterisation
Setting range (min. value | unit | max. value) Lenze setting
-214748.3647 Unit 214748.3647 0.0000 Unit
 Read access  Write access  CINH  PLC STOP  No transfer Scaling factor: 10000
Parameter | Name:
C02925 | Change Cam Data Point Y
Data type: INTEGER_32
Index: 21650
d
= 5492
h
 Changing cam data via parameterisation
Setting range (min. value | unit | max. value) Lenze setting
-214748.3647 Unit 214748.3647 0.0000 Unit
 Read access  Write access  CINH  PLC STOP  No transfer Scaling factor: 10000
Parameter | Name:
C02926 | Change Cam Data Point M
Data type: INTEGER_32
Index: 21649
d
= 5491
h
 Changing cam data via parameterisation
Setting range (min. value | unit | max. value) Lenze setting
-200.00 % 200.00 0.00 %
 Read access  Write access  CINH  PLC STOP  No transfer Scaling factor: 100
Parameter | Name:
C02927 | Auto Inc Cam Data Points
Data type: UNSIGNED_32
Index: 21648
d
= 5490
h
 Changing cam data via parameterisation
Selection list (Lenze setting printed in bold)
0 Deactivate
1 Activate
 Read access  Write access  CINH  PLC STOP  No transfer Scaling factor: 1
