Lenze · 9400 Servo PLC· Reference manual · DMS 4.0 EN · 11/2013 · TD05/06
647
14
Diagnostics & fault analysis
14.7
Error messages of the operating system
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
14.7.3
Short overview (A-Z)
The following table contains all error messages of the controller operating system in alphabetical
order with the preset error response and - if available – the parameter for setting the error response.
Tip!
If you click on the cross-reference in the first column, you get to the detailed description of
the corresponding error response in the following chapter "
".
Note!
Error message "Unknown error"
If the "Unknown error xxxx" error message is indicated in the logbook or in
reason for the missing plain text is that the error texts required have not been
downloaded to the controller during the application download.
• This, for instance, is the case if a device module plugged into the controller has not
been included in the Engineer project.
• Remedy: Include the device module, recompile and download the project.
hex
dec
Error message
Response (Lenze setting)
can be set in
8060991
A mains phase has failed
Fault
-
8060954
Absolute value encoder: Communication error
Fault
-
12058636
Acceleration has been limited
Information
8060946
Actual speed value outside tolerance (C00576)
No response
8192000
Analog input 1: master current < 4 mA
Fault
9175052
Application and device are incompatible
Fault
-
6946835
Application has started
Information
-
6946830
Application has stopped
Information
-
6946836
Application has stopped
Information
-
9502738
Block function in wrong MEC task
Fault
-
8060992
Brake chopper: Ixt > C00570
Warning
8060993
Brake resistor: I2t > C00572
Warning
8060957
Brake resistor: I²xt overload
Information
-
8060956
Brake transistor: Ixt overload
No response
8060961
Brake transistor: Overcurrent
Fault
-
6946831
Breakpoint reached
Information
-
12058644
Cam Data is corrupted
Warning locked
-
12058646
Cam Data locked due to wrong password
Warning locked
-
12058647
Cam Data locked due to wrong security key
Warning locked
-
12058645
Cam Data restored
Fault
-
12058677
Cam Data: Invalid product number
Information
-
12058676
Cam Data: Invalidated (due to change of mechanical data)
Warning
-
12058643
Cam data: serial number MM does not match
Warning locked
-
10551304
CAN module (MXI1) PDO manager: Faulty configuration
Warning locked
-
10551296
CAN module (MXI1) RPDO1: Telegram not received or faulty
No response
C13591/1
10551297
CAN module (MXI1) RPDO2: Telegram not received or faulty
No response
C13591/2
10551298
CAN module (MXI1) RPDO3: Telegram not received or faulty
No response
C13591/3
10551299
CAN module (MXI1) RPDO4: Telegram not received or faulty
No response
C13591/4
10551300
CAN module (MXI1) RPDO5: Telegram not received or faulty
No response
C13591/5
